A Proctor Group Frameshield 100 Condensation Control Breather Grey Membrane – 100m X 1.4m Roll

This Frameshield 100 Breather Membrane is suitable for use in timber frame wall construction and light steel frame applications, protecting against wind-driven rain, snow and dust. Once completed, it allows the controlled escape of vapour from within the timber frame, thanks to its high vapour permeability, whilst restricting the ingress of rain and moisture.

This Frameshield 100 membrane is supplied in roll form and should be fixed to frames with austenitic stainless steel nails or staples at centres not more than 500mm. Ensure its integrity by overlapping upper layers over lower layers and staggering vertical joints. Once applied to the wall, it should be covered within three months.

Features & Benefits: A Proctor Group Frameshield 100 Condensation Control Breather Grey Membrane – 100m x 1.4m Roll

• Provides effective protection during construction
• High water permeability
• Restricts ingress of rain and moisture
• Applied in the factory during manufacture or on sit
• Spunbonded, polypropylene material
• Water Vapour Resistance Sd: 0.006m

Standards & Certification

• Conforms to BS4016
