Xtratherm TR/MG Tapered Roof Board 90-110mm – 5.76m2

Made from LPC/FM-approved non-deleterious materials without the use of CFCs and HCFCs, Xtratherm TR/MG is a Polyisocyanurate with mineral-coated glass facers. It is high performing with a thermal conductivity as low as 0.024W/mK and is compatible with new builds and refurbishment projects.

For implementing below single-ply fully adhered roof membranes, single-ply waterproofing systems, and partially bonded built-up felt, these insulation boards come in a pack of four. Each has a board size of 1.44m² while the foam core density is 32 kg/m³. They also feature a layer of bitumen on a 3G type felt to BS 747 that has been deck-adhered.

Features & Benefits: Xtratherm TR/MG Tapered Roof Board 90-110mm – 5.76m2

• 1200mm length x 1200mm width x 90-110mm thickness
• Zero ODP and Low GWP
• Compressive Strength: >150 kPa @ 10% compression
• Fall: 1:60
• Thermal conductivity: 0.024 – 0.027 W/mK
• Compatible with adhesively bonded single-ply roofing membranes laid on mechanically fixed boards
• Board size of 1.44m²
• Pack of four
• 5.76m² pack
• Foam core density of 32 kg/m³

This product is suited to fully bonding with approved adhesives and making a practical water ponding solution with a single system for insulation and drainage.
